| PMDC MOTOR Technical Date | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-380SH | 4052 | 3.0~6.0 | 4.8VDC | 7800 | 0.32 | 6701 | 1.95 | 9.9/101 | 6.98 | 11.9 | 70.6/720 |
| 3557 | 6.0~12.0 | 12VDC | 21200 | 0.44 | 18367 | 2.85 | 11.26/114.9 | 21.68 | 18.5 | 84.3/860 | |
| RS-385SH | 17110 | 6.0~24.0 | 24VDC | 11000 | 0.15 | 9034 | 0.69 | 10.7/109 | 10.12 | 3.16 | 59.8/610 |
| 2267 | 6.0~12.0 | 12VDC | 10000 | 0.17 | 8340 | 0.85 | 7.5/76.5 | 6.53 | 4.29 | 45/459 | |
A1: Our RS-380 micro PMDC motors support a flexible operating voltage range, standard configurations include operating ranges from 3.0V to 6.0V (nominal at 4.8V) and 6.0V to 12.0V (nominal at 12V).
A2: Depending on the specific configuration and voltage applied, the RS-380 high-speed motor can reach no-load speeds ranging from 7,800 RPM up to 21,200 RPM, with rated speeds up to 18,367 RPM under standard load.
A3: Yes. We support customized specifications including voltage adjustments, shaft dimensions, speed variation, and torque modifications. Please reach out to provide your specific requirements.
A4: The difference lies primarily in the operational characteristics and voltage ranges. For instance, the RS-385 models are typically optimized for higher voltage applications up to 24V with standard nominal speeds around 10,000 to 11,000 RPM, offering different stall torque thresholds.
A5: These high-speed micro DC motors are widely used in home appliances, electronic tools, personal care products, automatic machinery, smart toys, and precise robotic components.
A6: Stall torque metrics are detailed in our reference datasheet. For example, the RS-380SH (12V) model offers a stall torque of 84.3 mN.m (860 gf.cm), while the RS-385SH (24V) model provides 59.8 mN.m (610 gf.cm).
